KATO Prewinder Air (KPA)

KATO Prewinder Air Tool

The Widest Range of Sizes

The KATO Prewinder Air (KPA) installation tool is designed for medium to high volume users of KATO Tangless and tanged strip-feed package CoilThread inserts (can also be used with bulk inserts). The KATO Prewinder Air tool is comprised of the KATO Air Motor (CT25017), KATO Adapter (CT9605 or CT9705), and a Front End Assembly. When used together, the KPA tool is capable of installing KATO CoilThread inserts up to 1/2” and M12 coarse and fine thread sizes

Another important component to the air tool system is the KATO Filter-Regulator-Lubricator (2KFRL-1). The Filter-Regulator-Lubricator cleans the air, allows precise control of the air pressure, and lubricates the air motor. In addition, the KPA tool features semi-automatic installation; press the lever to install the insert, release the lever and the air motor reverses.

For installation of Tangless CoilThread Inserts sizes: 2-56, 4-40, M2.5, and M3, the KATO torque limiting Clutch Drive (CT9602) is required to control the installation torque generated by the air motor, and prevent damage to the Front-End Assembly. The KATO Prewinder Air tool will also work with Helicoil and Recoil brand inserts, and some components may be interchangeable with Helicoil and Recoil brand tools. For more information contact KATO Support. To see the KATO Prewinder Air in action! Please visit our Video Workshop in Katopedia.

Prewinder Air Tool Components

Air Motor

Air Motor (CT25017)

(CT25017)

The powerful KPA Motor is designed to install Tangless or tanged CoilThead inserts for sizes up to 1/2" and M12 coarse and fine thread sizes.

Adapters

KPA Adapter (CT9605 and CT9705)

(CT9605 or CT9705)

The KPA Adapter acts as a bridge between the air motor and the front-end assembly.

Front-End Assembly

Front-End Assembly

(See Part No.)

The Front-End Assembly is available for a variety of thread sizes and is designed to install 1, 1.5 and 2 diameter nominal length inserts. For information on specific sizes, see Part Numbers.

Filter-Regulator-Lubricator

Filter-Regulator-Lubricator (2KRL-1)

(2KFRL-1)

The Filter-Regulator-Lubricator is critical to the longevity of the pneumatic system. Each front-end assembly is stamped with a maximum air pressure, the filter-regulator-lubricator ensures the air pressure never exceeds that value. A Filter-Regulator Lubricator is required for each air motor in operation.


Torque Limiting Clutch Drive

Torque Liminting Clutch Drive (CT9602)

(CT9602)

The KATO Torque Limiting Clutch-Drive was designed with one goal in mind: to prolong the life of your air tool mandrels and prevent breakage under excessive torque. Note: The Clutch Drive is required for Tangless 2-56, 4-40, M2.5 and M3 thread sizes.

Features & Benefits

  • Ideal for use with strip feed inserts (for sizes 1/4", M6 and smaller).
  • Prewinder threads help facilitate installation. This is especially helpful when installing UNF or Metric thread sizes.
  • Installs a broad range of sizes for both Tangless and tanged inserts (2-56 thru 1/2" & M2.5 to M12).
  • Semi-Automatic Installation for decreases installation time
  • Compatiable with screw thread inserts from Helicoil, Recoil and others.
  • Utilizes KATO's One Pawl Fits All system (Tangless only).
KATO Linear Torque Arm with Optional Air Tool Kit

New KATO Linear Torque Arm Shown with Optional Air Tool Kit


To boost productivity use the KATO Linear Arm with optional air tool kit, with KATO strip-feed packaged Tangless inserts, and the KATO Prewinder Air tool (2KPA series). For the fastest and most productive semi-automatic installation system consider using the KATO Prewinder Electric tool (2KPE series).

Learn More.

Part Numbers


For fast and accurate part numbers and technical information on specific inserts try out the KATO Product Wizard.

Example of a KATO Prewinder Air tool part number:


2 KPA C - 02

1    2   3   4    5


1
Tool Type		 2
Tool Style		 3
Thread Designation		 4
Size Designation		 5
Component / Replacement Part
Blank - For CoilThread (Tanged)
2 - Prefix for CoilThread II Tangless inserts 		KPA - KATO Prewinder Air
 C - Unified Coarse
F - Unified Fine
M - Metric		 Chart Below D - Prewinder Body
M - Mandrel Assembly (Tangless mandrel includes, pawl, pin, and spring fully assembled and ready for use)
S - Spacer Set (includes 3 spacers + 1 thick shim + 3 thin shims, where applicable)

How to Order:


Thread
Size		 Tangless
Front End Assembly2		 Tanged
Front End Assembly2		 Torque Limiting
Clutch Drive 1		 Air Motor Adapter Filter
Regulator
Lubricator		 Linear Torque
Arm & Kit
Unified Coarse
2-562KPAC-02KPAC-02CT9602CT25017CT96052KFRL-12KLRM-1
2KLRM-1A
4-402KPAC-04KPAC-04
6-322KPAC-06KPAC-06---
8-322KPAC-2KPAC-2
10-242KPAC-3KPAC-3
1/4-202KPAC-4KPAC-4
5/16-182KPAC-5KPAC-5CT9705
3/8-162KPAC-6KPAC-6
7/16-14---KPAC-7
1/2-13---KPAC-8
Unified Fine
6-40---KPAF-06---CT25017CT96052KFRL-12KLRM-1
2KLRM-1A
8-36---KPAF-2
10-322KPAF-3KPAF-3
1/4-282KPAF-4KPAF-4
5/16-242KPAF-5KPAF-5CT9705
3/8-242KPAF-6KPAF-6
7/16-2032KPAF-F7
2KPAF-L7		KPAF-7
1/2-2032KPAF-F8
2KPAF-L8 		KPAF-8
Metric Coarse
M2.5X.452KPAM-2.5KPAM-2.5CT9602CT25017CT96052KFRL-12KLRM-1
2KLRM-1A
M3X.52KPAM-3KPAM-3
M3.5X.6---KPAM-3.5
M4X.72KPAM-4KPAM-4---
M5X.82KPAM-5KPAM-5
M6X12KPAM-6KPAM-6
M7X1---KPAM-7
M8X1.252KPAM-8KPAM-8CT9705
M10X1.52KPAM-10KPAM-10
M12X1.752KPAM-12KPAM-12
Metric Fine
M8X1---KPAM-8X1 ---CT25017CT97052KFRL-12KLRM-1
2KLRM-1A
M10X1---KPAM-10X1
M10X1.25---KPAM-10X1.25
M12X1.25---KPAM-12X1.25
M12X1.5---KPAM-12X1.5

Please Note:

  1. The Torque Limiting Clutch Drive must be used with Tangless thread sizes 2-56, 4-40, M2.5 & M3. KATO will not warrantee the mandrels or pawls without the use of the Clutch Drive.
  2. The Front End Assembly is designed to work with 1, 1.5, and 2 diameter inserts, for 2.5 and 3 diameter inserts, please contact KATO for availability.
  3. For Improved Tangless installation UNF & Metric thread sizes use a different installation mandrel for Free-Running and Locking CoilThread inserts, this is indicated by the -F and -L designation in the part number.

Tangless Replacement Parts

Thread
Size		 Replacement
Pawl		 Replacement
Pawl Kit1		 Prewinder
Body		 Mandrel
Assembly		 Spacer
Set
Unified Coarse
2-562KIPC-022KIPC-02K2KPAC-02D2KPAC-02M2KPAC-02S
4-402KIPC-042KIPC-04K2KPAC-04D2KPAC-04M2KPAC-04S
6-322KIPC-062KIPC-06K2KPAC-06D2KPAC-06M2KPAC-06S
8-322KIPC-22KIPC-2K2KPAC-2D2KPAC-2M2KPAC-2S
10-242KIPC-32KIPC-3K2KPAC-3D2KPAC-3M2KPAC-3S
1/4-202KIPC-42KIPC-4K2KPAC-4D2KPAC-4M2KPAC-4S
5/16-182KIPC-52KIPC-5K2KPAC-5D2KPAC-5M2KPAC-5S
3/8-162KIPC-62KIPC-6K2KPAC-6D2KPAC-6M2KPAC-6S
Unified Fine
10-322KIPC-32KIPF-3K2KPAF-3D2KPAF-3M2KPAF-3S
1/4-282KIPC-42KIPF-4K2KPAF-4D2KPAF-4M2KPAF-4S
5/16-242KIPC-52KIPF-5K2KPAF-5D2KPAF-5M2KPAF-5S
3/8-242KIPC-62KIPF-6K2KPAF-6D2KPAF-6M2KPAF-6S
7/16-202KIPF-72KIPF-7K2KPAF-F7D
2KPAF-L7D		2KPAF-F7M
2KPAF-L7M		2KPAF-7S
1/2-202KIPF-82KIPF-8K2KPAF-F8D
2KPAF-L8D 		2KPAF-F8M
2KPAF-L8M 		2KPAF-8S
Metric Coarse
M2.5X.452KIPM-2.52KIPM-2.5K2KPAM-2.5D2KPAM-2.5M2KPAM-2.5S
M3X.52KIPM-32KIPM-3K2KPAM-3D2KPAM-3M2KPAM-3S
M4X.72KIPM-42KIPM-4K2KPAM-4D2KPAM-4M2KPAM-4S
M5X.82KIPM-52KIPM-5K2KPAM-5D2KPAM-5M2KPAM-5S
M6X12KIPM-62KIPM-6K2KPAM-6D2KPAM-6M2KPAM-6S
M8X1.252KIPM-82KIPM-8K2KPAM-8D2KPAM-8M2KPAM-8S
M10X1.52KIPM-102KIPM-10K2KPAM-10D2KPAM-10M2KPAM-10S
M12X1.752KIPM-122KIPM-12K2KPAM-12D2KPAM-12M2KPAM-12S

Please Note:

  1. Replacement Pawl Kit - includes one pawl, two pins, and two springs.

Tanged Replacement Parts

Thread
Size		 Prewinder
Body		 Mandrel
Assembly		 Spacer
Set
Unified Coarse
2-56KPAC-02DKPAC-02MKPAC-02S
4-40KPAC-04DKPAC-04MKPAC-04S
6-32KPAC-06DKPAC-06MKPAC-06S
8-32KPAC-2DKPAC-2MKPAC-2S
10-24KPAC-3DKPAC-3MKPAC-3S
1/4-20KPAC-4DKPAC-4MKPAC-4S
5/16-18KPAC-5DKPAC-5MKPAC-5S
3/8-16KPAC-6DKPAC-6MKPAC-6S
7/16-14KPAC-7DKPAC-7MKPAC-7S
1/2-13KPAC-8DKPAC-8MKPAC-8S
Unified Fine
6-40KPAF-06DKPAF-06MKPAF-06S
8-36KPAF-2DKPAF-2MKPAF-2S
10-32KPAF-3DKPAF-3MKPAF-3S
1/4-28KPAF-4DKPAF-4MKPAF-4S
5/16-24KPAF-5DKPAF-5MKPAF-5S
3/8-24KPAF-6DKPAF-6MKPAF-6S
7/16-20KPAF-7DKPAF-7MKPAF-7S
1/2-20KPAF-8DKPAF-8MKPAF-8S
Metric Coarse
M2.5X.45KPAM-2.5DKPAM-2.5MKPAM-2.5S
M3X.5KPAM-3DKPAM-3MKPAM-3S
M3.5X.6KPAM-3.5DKPAM-3.5MKPAM-3.5S
M4X.7KPAM-4DKPAM-4MKPAM-4S
M5X.8KPAM-5DKPAM-5MKPAM-5S
M6X1KPAM-6DKPAM-6MKPAM-6S
M7X1KPAM-7DKPAM-7MKPAM-7S
M8X1.25KPAM-8DKPAM-8MKPAM-8S
M10X1.5KPAM-10DKPAM-10MKPAM-10S
M12X1.75KPAM-12DKPAM-12MKPAM-12S
Metric Fine
M8X1KPAM-8X1DKPAM-8X1MKPAM-8X1S
M10X1KPAM-10X1DKPAM-10X1MKPAM-10X1S
M10X1.25KPAM-10X1.25DKPAM-10X1.25MKPAM-10X1.25S
M12X1.25KPAM-12X1.25DKPAM-12X1.25MKPAM-12X1.25S
M12X1.5KPAM-12X1.5DKPAM-12X1.5MKPAM-12X1.5S

Specifications

All dimensions for unified size (in.) | All dimensions are are for reference only.

Air Motor with Prewinder Adapter

Air Prewinder Tool Prewinder Electric
Thread
Size		 A B ∅C ∅D Weight
FEA
(lbs)		 ∅E F Max RPM
at 90 PSI 		Weight
Air Motor 		Air
Motor
Torque3		 Weight
Complete
Tool		 Hose
Fitting
Unified Coarse
2-56100.970.180.340.111.253.001500.838lb
(393.8g)		.9191.4lb1/4"NPT
4-40101.090.260.400.11
6-32101.250.310.500.11
8-32101.050.350.510.13
10-24101.340.370.510.13
1/4-20101.440.420.630.13
5/16-18111.250.560.750.351.554.002lb
3/8-16112.010.690.880.35
7/16-14121.870.750.750.35
1/2-13122.210.810.810.35
Unified Fine
6-40101.030.310.500.111.253.001500.838lb
(393.8g)		.9191.4lb1/4"NPT
8-36101.050.350.510.11
10-32101.020.380.620.11
1/4-28101.230.430.630.11
5/16-24121.930.560.750.351.554.002lb
3/8-24122.040.690.870.35
7/16-20121.870.750.750.35
1/2-20122.300.820.820.35
Metric Coarse
M2.5X.45101.470.390.390.111.253.001500.838lb
(393.8g)		.9191.4lb1/4"NPT
M3X.5101.380.370.510.11
M3.5X.6101.380.370.510.11
M4X.7101.020.350.490.13
M5X.8101.000.240.390.13
M6X1101.480.390.630.13
M7X1101.480.430.630.35
M8X1.25121.330.560.750.351.554.002lb
M10X1.5122.150.880.880.35
M12X1.75122.280.810.810.35
Metric Fine
M8X1121.3260.5630.5630.351.554.001500.838lb
(393.8g)		.9192lb1/4"NPT
M10X1122.1520.8750.8750.35
M10X1.25122.1520.8750.8750.35
M12X1.25122.2820.8140.8140.35
M12X1.5122.2820.8140.8140.35

Please Note:

  1. Dimensions listed are for standard length front end assembly (1, 1.5, & 2 Diameter).
  2. For thread sizes 2-56 to 1/4" and M2.5 to M6 use KATO Adapter CT9605. For thread sizes 5/16" to 1/2" and M8 to M12 use the KATO Adapter CT9705. For the air motor technical manual visit, KATOpedia.
  3. Torque (lbf-ft) is calculated based on .14hp @ 800 rpm.

PSI-Chart

Thread
Size		Tangless FEA
Part Number		Tangless Max.
PSI		Tanged FEA
Part Number		Tanged Max.
PSI
Unified Sizes
2-562KPAC-0215KPAC-0220
4-402KPAC-0420KPAC-0420
6-322KPAC-0630KPAC-0630
8-322KPAC-230KPAC-240
10-242KPAC-340KPAC-340
10-322KPAF-330KPAF-340
1/4-202KPAC-445KPAC-445
1/4-282KPAF-445KPAF-445
5/16-182KPAC-550KPAC-550
5/16-242KPAF-550KPAF-550
3/8-162KPAC-660KPAC-660
3/8-242KPAF-660KPAF-660
7/16-14------KPAC-760
1/2-13------KPAC-880
Metric Sizes
M2.5X0.452KPAM-2.515KPAM-2.520
M3X.52KPAM-320KPAM-330
M3.5X.6------KPAM-3.540
M4X.72KPAM-430KPAM-440
M5X.82KPAM-530KPAM-540
M6X12KPAM-640KPAM-645
M7X1------KPAM-745
M8X1.252KPAM-850KPAM-850
M10X1.5------KPAM-1050
M12X1.75------KPAM-1260

Cross Reference


Tangless
KATO
Part Number		 Superseded
Part Number		 Helicoil
Part Number
Unified Coarse
2KPAC-022CT11000-0218551-02-15
2KPAC-02M2CT11200-0218551-02-30
2KPAC-042CT11000-0418551-04-15
2KPAC-04M2CT11200-0418551-04-30
2KPAC-062CT11000-0618551-06-15
2KPAC-06M2CT11200-0618551-06-30
2KPAC-22CT11000-218551-2-15
2KPAC-2M2CT11200-218551-2-30
2KPAC-32CT11000-318551-3-15
2KPAC-3M2CT11200-318551-3-30
2KPAC-42CT11000-418551-4-15
2KPAC-4M2CT11200-418551-4-30
2KPAC-52CT11000-5---
2KPAC-5M2CT11200-5---
2KPAC-62CT11000-6---
2KPAC-6M2CT11200-6---
Unified Fine
2KPAF-32CT11001-3A18552-3-15
2KPAF-3M2CT11201-3A18552-3-30
2KPAF-42CT11001-418552-4-15
2KPAF-4M2CT11201-418552-4-30
2KPAF-52CT11001-5---
2KPAF-5M2CT11201-5---
2KPAF-62CT11001-6---
2KPAF-6M2CT11201-6---
Metric Coarse
2KPAM-2.52CT11000-M2.5---
2KPAM-2.5M2CT11200-M2.5---
2KPAM-32CT11000-M3---
2KPAM-3M2CT11200-M3---
2KPAM-42CT11000-M4---
2KPAM-4M2CT11200-M4---
2KPAM-52CT11000-M5---
2KPAM-5M2CT11200-M5---
2KPAM-62CT11000-M6---
2KPAM-6M2CT11200-M6---
2KPAM-82CT11000-M8---
2KPAM-8M2CT11200-M8---
2KPAM-102CT11000-M10---
2KPAM-10M2CT11200-M10---
2KPAM-122CT11000-M12---
2KPAM-12M2CT11200-M12---
Tanged
KATO
Part Number		 Superseded
Part Number		 Helicoil
Part Number
Unified Coarse
KPAC-02CT11000-028551-02-15
KPAC-02MCT11200-028553-02
KPAC-04CT11000-048551-04-15
KPAC-04MCT11200-048553-04
KPAC-06CT11000-068551-06-15
KPAC-06MCT11200-068553-06
KPAC-2CT11000-28551-2-15
KPAC-2MCT11200-28553-2
KPAC-3CT11000-38551-3-15
KPAC-3MCT11200-38553-3
KPAC-4CT11000-48551-4-15
KPAC-4MCT11200-48553-4
KPAC-5CT11000-58551-5-15
KPAC-5MCT11200-58253-5
KPAC-6CT11000-68251-6
KPAC-6MCT11200-68253-6
KPAC-7CT11000-78251-7
KPAC-7MCT11200-78253-7
KPAC-8CT11000-88251-8
KPAC-8MCT11200-88253-8
Unified Fine
KPAF-06CT11001-068552-06
KPAF-06MCT11201-068554-06
KPAF-2CT11001-2---
KPAF-2MCT11201-2---
KPAF-3CT11001-38552-3-15
KPAF-3MCT11201-38554-3
KPAF-4CT11001-48552-4-15
KPAF-4MCT11201-48554-4
KPAF-5CT11001-58552-5-15
KPAF-5MCT11201-58254-5
KPAF-6CT11001-68252-6
KPAF-6MCT11201-68254-6
KPAF-7CT11001-78252-7
KPAF-7MCT11201-78254-7
KPAF-8CT11001-88252-8
KPAF-8MCT11201-88254-8
Tanged
KATO
Part Number		 Superseded
Part Number		 Helicoil
Part Number
Metric Coarse
KPAM-2.5CT11000-M2.58751-2.5
KPAM-2.5MCT11200-M2.58757-2.5
KPAM-3CT11000-M38751-3
KPAM-3MCT11200-M38757-3
KPAM-3.5CT11000-M3.58751-3.5
KPAM-3.5MCT11200-M3.58757-3.5
KPAM-4CT11000-M48751-4
KPAM-4MCT11200-M48757-4
KPAM-5CT11000-M58751-5
KPAM-5MCT11200-M58757-5
KPAM-6CT11000-M68751-6
KPAM-6MCT11200-M68757-6
KPAM-7CT11000-M78751-7
KPAM-7MCT11200-M78757-7
KPAM-8CT11000-M88751-8
KPAM-8MCT11200-M88757-8
KPAM-10CT11000-M108751-10
KPAM-10MCT11200-M108757-10
KPAM-12CT11000-M128751-12
KPAM-12MCT11200-M128757-12
Metric Fine
KPAM-8X1CT11000-M8X18755-8
KPAM-8X1MCT11200-M8X18764-8
KPAM-10X1CT11000-M10X18755-10
KPAM-10X1MCT11200-M10X18764-10
KPAM-10X1.25CT11000-M10X1.258756-10
KPAM-10X1.25MCT11200-M10X1.258759-10
KPAM-12X1.25CT11000-M12X1.258756-12
KPAM-12X1.25MCT11200-M12X1.258759-12
KPAM-12X1.5CT11000-M12X1.58753-12
KPAM-12X1.5MCT11200-M12X1.58774-12

Please Note:

  • KATO CT25017 cross references to Helicoil 8510-1 part number.
  • KATO CT9605 cross references to Helicoil 8550R part number.
  • KATO CT9705 cross references to Helicoil 8550-1R part number.
  • Tanged mandrels may not be interchangeable with Helicoil prewinders. Please contact KATO support for confirmation.

Feedback

Your feedback is important to us! Receive your complimentary gift.

Take Survey

Contact Us

757.873.8980

757.873.4920

Email us

Products

Website
